Hi,

can anyone please help me on how to call workflow in Touch UI.

This post is no longer active and is closed to new replies. Need help? Start a new post to ask your question.

Best answer by Hemant_arora

Make an jquery ajax call to a sling servlet which further call the workflow through API

Refer to example below.

You must also look into solution by smacdonald2008

There are only 2 methods (not counting the Deprecated one) exposed in the WorkFlowSession Class that starts a workflow:

`Workflow`	`startWorkflow(WorkflowModel model, WorkflowData data)` Start a new `Workflow` instance with the given `WorkflowModel` and `WorkflowData`.
`Workflow`	`startWorkflow(WorkflowModel model, WorkflowData data, Dictionary<String,String> metaData)` Deprecated. It's recommended to use `#startWorkflow(WorkflowModel, WorkflowData, Map instead.`
`Workflow`	`startWorkflow(WorkflowModel model, WorkflowData data, Map<String,Object> metaData)` Start a new `Workflow` instance with the given `WorkflowModel`, `WorkflowData` and `meta data`.

Therefore you need a WorkflowModel and data,

In your use case - you need these as input - else it will not work.

New Participant

Great answer!

Hemant_aroraAccepted solution

New Participant

Make an jquery ajax call to a sling servlet which further call the workflow through API

Refer to example below.

You must also look into solution by smacdonald2008

There are only 2 methods (not counting the Deprecated one) exposed in the WorkFlowSession Class that starts a workflow:

`Workflow`	`startWorkflow(WorkflowModel model, WorkflowData data)` Start a new `Workflow` instance with the given `WorkflowModel` and `WorkflowData`.
`Workflow`	`startWorkflow(WorkflowModel model, WorkflowData data, Dictionary<String,String> metaData)` Deprecated. It's recommended to use `#startWorkflow(WorkflowModel, WorkflowData, Map instead.`
`Workflow`	`startWorkflow(WorkflowModel model, WorkflowData data, Map<String,Object> metaData)` Start a new `Workflow` instance with the given `WorkflowModel`, `WorkflowData` and `meta data`.
